AC Magnetic

Ac magnetic dinar imagwiritsidwa ntchito mu netiweki yamagetsi ya ac 50hz kapena 60hz, mpaka 380V, pogwiritsa ntchito chipangizo chowongolera cha LV. Pokhala ndi chipangizo cha anisirge, chimatha kuchepetsa kuchepa kwa kapasi komanso kupewa kuchuluka kwambiri ngati kusweka.

Tumizani Kufunsira

Mafotokozedwe Akatundu

Mtundu		CJ19-09	CJ19-12	CJ19-18	CJ19-25	CJ19-32	CJ19-40	CJ19-50	CJ19-65	CJ19-80	CJ19-95
Adavotera ntchito zamakono (a)	AC3	9	12	18	25	32	40	50	65	80	95
Adavotera ntchito zamakono (a)	Ac4	3.5	5	7.7	8.5	12	18.5	24	28	37	44
Mavoti ogwirizana ndi gawo la 3-gawo matope 50 / 60hz	220 / 230v	2.2	3	4	5.5	7.5	11	15	18.5	22	25
	380 / 400V	4	5.5	7.5	11	15	18.5	22	30	37	45
	415V	4	5.5	9	11	15	22	25	37	45	45
	500V	5.5	7.5	10	15	18.5	22	30	37	55	55
	660 / 690V	5.5	7.5	10	15	18.5	30	33	37	45	55
Ophimbidwa pamasamba (a)		20	20	32	40	50	60	80	80	125	125
Moyo wamagetsi	Ac3 (x104)	100	100	100	100	80	80	60	60	60	60
Moyo wamagetsi	Ac4 (x104)	20	20	20	20	20	15	15	15	10	10
Moyo wamakina (x104)		1000	1000	1000	1000	800	800	800	800	600	600
Chiwerengero cha Olumikizana	3p + ayi					3p + NC + ayi
Chiwerengero cha Olumikizana	3p + NC					3p + NC + ayi

ScJ19 Kusinthanitsa mtundu wa mtundu wa ENARE kumagwiritsidwa ntchito mu network ya ma ac 50hz kapena 60hz, mpaka 380V, pogwiritsa ntchito chipangizo chowongolera cha LV ovomerezeka mu LV. Pokhala ndi chipangizo cha anisirge, chimatha kuchepetsa kuchepa kwa kapasi komanso kupewa kuchuluka kwambiri ngati kusweka.

Mfundo yofunika kugwirira ntchito

Mfundo yogwira ntchito ya AC Magnetic imachokera ku electromagnetic inctioction ndi mphamvu yamagetsi. Pomwe coil imapatsidwa mphamvu, mphamvu yamagetsi yomwe imatulutsa pachimake ndikutseka machezawo, ndikutsegula dera. Chipindacho chikaphatikizidwa, mphamvu yamagetsi itasokonekera, malo osungirako zitsulo omwe ali ndi kasupe, kulumikizana kumasweka ndipo dera limasambitsidwa. Mwanjira imeneyi, kugonana kwa ac maginito kumazindikira kuwongolera kagawo ka ma AC.

Kapangidwe ndi kapangidwe kake

Ac magnetic dinar makamaka ndi gawo lotsatira:

Makina a Electromagnetic: Amaphatikizanso zigawo monga coil, core ndi zida zankhondo, zomwe ndizofunikira kwambiri pamunda wamagalasi ndi maginito.

Njira Yolumikizana ndi: imaphatikizapo kulumikizana kwakukulu ndi zokhudzana ndi othandizira, omwe amagwiritsidwa ntchito kuyatsa ndi kuzungulira. Olumikizira akulu nthawi zambiri amagwiritsidwa ntchito kunyamula chiyeta chachikulu, pomwe othandizira othandiza amagwiritsidwa ntchito kuzindikira osiyanasiyana kuwongolera.

Chida cha Arc chowoneka bwino: chomwe chimagwiritsidwa ntchito kuzimitsa marc mukalumikizidwa, kupewa arc kuti asawononge kulumikizana.

Zida zina: monga akasupe, mabatani, nyumba, ndi zina zambiri, zimagwiritsidwa ntchito kukonza ndikuthandizira zigawozo kuti zitsimikizire kuti amagwiritsa ntchito.

Kapangidwe kake

1.Mupangiri yemwe anasonkhana ndi kukana kochepa kumene, wokhoza kuchepetsa kusachedwa-patali wovomerezeka.

2.Mupangiri ndi kapangidwe kakang'ono kopitilira muyeso, njira yogwirira ntchito ndi yoyeserera, yosavuta kuyang'ana ndi dzanja, zojambulajambula zojambula kuti zithetse anzanu.

3.Kuping wamkulu wotetezedwa ndi chivundikiro, otetezeka komanso odalirika.

4.Imayikidwa ndi zomangira, kapena pa 35 / 75mm Standard.

Kugwira Ntchito ndi Kukhazikitsa

(1) Kutentha kozungulira: --5 ℃ - 40 ℃, kutentha kwapakati sikuyenera kupitirira + 35 ℃ mu maola 24.

(2) Mikhalidwe yamlengalenga: Mkhalidwe wowoneka bwino pansi pa 50% + 40 ℃. Mu mwezi wonyowa wapakati kutentha kwambiri + 25 ℃ Pafupifupi ndi 10%, ndikuwona kutentha kumasintha ndikuchitika chifukwa cha gelisi.

(3) Kutali konse kuposa 2000m pakuyika.

(4) Kalasi yolosera: 3

(5) Kalasi ya kukhazikitsa: III

Mawonekedwe akulu

Kugwira ntchito modalirika: Ac Magnetic amapangidwa ndi zida zapamwamba komanso zotsogola zapamwamba, zomwe zimakhala ndi kudalirika kwakukulu komanso kukhazikika.

Moyo wautali: Kampani yolumikizana imapangidwa ndi zida zosalimbana ndi zofooka, zomwe zimatha kupirira zikuluzikulu zazikulu ndi mphamvu, kutalikirana moyo wa ntchito.

Yosavuta Kusunga: Kapangidwe kake kamapangidwa, kosavuta kusokoneza ndikukonza, kuchepetsa mtengo wokonza.

Zosagwirizana zosiyanasiyana: Pofuna kukwaniritsa zosowa zosiyanasiyana ogwiritsa ntchito, maginito a Macmine
